Sawgrass SG1000 |
 |
|
|
|
 |
| What Do You Get With The Sawgrass SG1000? |
1 x Sawgrass SG1000 A3 Sublimation Printer
1 x Sublijet UHD Black Cartridge (20ml, 31ml or 70ml)
1 x Sublijet UHD Cyan Cartridge (20ml, 31ml or 70ml)
1 x Sublijet UHD Magenta Cartridge (20ml, 31ml or 70ml)
1 x Sublijet UHD Yellow Cartridge (20ml, 31ml or 70ml)
1 x Sawgrass Power Driver
1 x Creative Studio Software (PC / MAC) - (cloud based with licence)
1 x Power Cable
1 x 100 sheets Sawgrass Truepix A3 sublimation paper
There are 3 options for cartridges, you can get Starter Inks (20ml per cartridge), Full Capacity Inks (31ml per cartridge) or Extended Capacity Inks (70ml per cartridge)
|
|
|
Sawgrass SG1000 Features |
|
|
The Sawgrass SG1000 is a desktop A3 dye sublimation printer.
Dye sublimation is a process where you print your artwork using special inks onto special paper. You then apply this to specially receptive products, eg garments or mug using a heat press. At the correct temperature the ink turns into a gas and fuses into the product, giving a long lasting, vibrant image.
|
|
High Definition Printing
The SG1000 printers are the the only printers designed specifically for sublimation printing. Using the Sawgrass SubliJet-UHD inks, the SG1000 printer delivers the highest resolution prints possible for vibrant, ultra fine photo quality reproduction at up to 4880 x 1200 dpi.
Using a multi cartridge ink system (black, magenta, cyan and yellow), the SG1000 printer driver unleashes up to to 687,754 colours out of just those 4 cartridges and the new UHD inks gives deeper black than any other ink before.
Faster Speeds, Greater Productivity
The SG1000 is over twice as fast than their Ricoh predecessors and 50% faster than the SG400, meaning you can print up to 240 prints per hour. The printer has a built in self cleaning routine ensuring that the printer is running at its optimal performance.
Wi-Fi
The SG1000 comes as a wifi enabled printer, no longer restricting you to the length of your USB cable.
Easy Expansion Options
The optional Bypass Tray extends maximum media size up to 330x1295mm (13x51 inch).
|
 |
|
Service and Support
All SG1000 systems come with access to PartnerPlus, Sawgrass's comprehensive user support program which offers real time help with system troubleshooting and assistance with colour management software.
Warranty
All SG1000 Desktop HD Product Decorating Systems come with a two year warranty in the EU.
|
 |
|
|
Whilst you can use the SG1000 using an existing software package such as Corel or Photoshop, SG1000 printers come bundled with the feature rich Creative Studio 2020 software
|
|
Online Designer
Design from any internet-connected device - desktop, tablet or phone - no experience necessary. Quickly create proofs for your clients using Windows, Mac and Android platforms.
Product Templates At Your Fingertips
CreativeStudio has hundreds of product templates direct from the most popular substrate
manufacturers.
Image Library
Browse over 500 editable design templates and over 5,000 graphics, photos and images. Each image has been hand selected or designed for popular applications, such as sports products, personalised gifts, garment decoration and photo products.
Free Cloud Storage
Included with Creative Studio 2020 is free online storage of your templates, print-ready files and uploaded images.
CS Print Manager Web2Print Software
Design online and save to the cloud. With just a few clicks, you can
output these to your SG1000 printer using CS Print Manager software.
In A Rush?
Get up to speed quickly Creative Studio 2020 online video tutorials.
|
 |
|
|
| Sawgrass SG1000 Specification |
| General Specifications |
 |
| Maximum Media Size |
297x431mm sheet. Standard A3 sized media
330x482mm with optional bypass tray
330x1295mm with optional bypass tray |
| Display Panel |
LCD |
| Interface |
WiFi / USB 2.0 High Speed |
| Voltage |
220 / 240v |
| Warranty |
2 year return to base parts and labour |
| Unit Dimensions |
529(w) x 360(d) x 213(h)mm |
| Unit
Weight |
16Kg |
| Box
Dimensions |
700(w) x 550(d) x 340(h)mm |
| |
|
| Ink Cartridges |
| The printer is sold with a complete set of ink cartridges. |
| Replacement
consumables |
Standard Capacity
609101 Sawgrass SG1000 Sublijet UHD 31ml Black
609102 Sawgrass SG1000 Sublijet UHD 31ml Cyan
609103 Sawgrass SG1000 Sublijet UHD 31ml Magenta
609104 Sawgrass SG1000 Sublijet UHD 31ml Yellow
Extended Capacity
609231 Sawgrass SG1000 Sublijet UHD 70ml Black
609232 Sawgrass SG1000 Sublijet UHD 70ml Cyan
609233 Sawgrass SG1000 Sublijet UHD 70ml Magenta
609234 Sawgrass SG1000 Sublijet UHD 70ml Yellow
RSYSSG6450 Sawgrass Waste Ink Tank |
| |
|
| Print Speeds and Resolutions |
High Speed
High Quality
Advance Photo
Ultra Fine Photo
|
15 seconds
(600x600 dpi)
29 seconds
(600x600 dpi)
48 seconds
(1200x1200 dpi)
6 minutes 40 seconds
(4880x1200 dpi) |
| |
|
| Colour
Management Options for Desktop Graphic Software |
| PowerDriver 4.2 OS Recommendations* |
Windows 7, 8 Professional, Business, Enterprise, Ultimate |
| Mac Profile OS |
Recommendations* Mac OS 10.9 or later |
| Graphics Application Recommendations* |
Corel: CorelDraw X6 or Later / Adobe: Illustrator and Photoshop CS6
or Creative Cloud, Photoshop Elements 12 and Later |
| *Visit sawgrassink.com for a complete list of supported PowerDriver 4.2 OS and graphic software |
| |
| CreativeStudio Online Designer with CS Print and Color Manager |
| Designing: |
OS / Browser Recommendations Windows, Mac OS, Android / Chrome |
| Printing: OS Recommendations |
Windows 7, 8 Professional, Business, Enterprise, Ultimate / Mac OS 10.9 and later |
|
Power Supplies (UK and Euro Style Available)
All UK and Republic of Ireland orders are despatched with a UK 3 Pin plug power supply.
For all countries outside the UK and Republic of Ireland we will despatch your machine with a European 2 Pin power supply unless you specifically request the UK 3 Pin plug power supply.
|
|
